A dataview column. More...
#include <jdataview.h>
Data Fields | |
| t_symbol * | c_name |
| column name (hash) | |
| t_object * | c_dv |
| parent dataview | |
| int | c_id |
| id in DataViewComponent | |
| long | c_width |
| column width in pixels | |
| long | c_maxwidth |
| max column width | |
| long | c_minwidth |
| min column width | |
| char | c_autosize |
| determine width of text column automatically (true/false) | |
| char | c_alignment |
| display of text, left, right, center | |
| t_symbol * | c_font |
| name of font | |
| long | c_fontsize |
| font size (points?) | |
| t_symbol * | c_label |
| heading of column | |
| char | c_separator |
| separator mode | |
| char | c_button |
| column has a button (true/false) | |
| t_symbol * | c_buttonlabel |
| text in a button | |
| t_symbol * | c_customsort |
| message sent to sort this column -- if none, default sorting is used based on value c_numeric | |
| char | c_overridesort |
| if true only the sortdata method is called, not the sort method (true/false) | |
| t_symbol * | c_custompaint |
| send this msg name to client to paint this column | |
| t_symbol * | c_valuemsg |
| message sent when a component mode cell's value changes | |
| t_symbol * | c_beginmsg |
| message sent when a component mode cell's value is about to start changing | |
| t_symbol * | c_endmsg |
| message sent when a component mode cell's value is finished changing | |
| t_symbol * | c_rowcomponentmsg |
| message sent to determine what kind of component should be created for each cell in a column | |
| t_symbol * | c_custommenuset |
| message to set a menu (for a readonly or custompaint column) | |
| t_symbol * | c_custommenuresult |
| message sent when an item is chosen from a custom menu | |
| char | c_editable |
| can you edit the data in a cell in this column | |
| char | c_selectable |
| can select the data in a cell in this column (possibly without being able to edit) | |
| char | c_multiselectable |
| can you select more than one cell in this column | |
| char | c_sortable |
| can you click on a column heading to sort the data | |
| long | c_initiallysorted |
| if this is set to JCOLUMN_INITIALLYSORTED_FORWARDS the column is displayed with the sort triangle | |
| long | c_maxtextlen |
| maximum text length: this is used to allocate a buffer to pass to gettext (but there is also a constant) | |
| long | c_sortdirection |
| 0 for ascending, 1 for descending | |
| long | c_component |
| enum of components (check box etc.) | |
| char | c_canselect |
| can select entire column | |
| char | c_cancut |
| can cut/clear entire column | |
| char | c_cancopy |
| can copy entire column | |
| char | c_cancutcells |
| can cut a single cell (assumes "editable" or "selectable") (probably won't be implemented) | |
| char | c_cancopycells |
| can copy a single cell | |
| char | c_canpastecells |
| can paste into a single cell | |
| char | c_hideable |
| can the column be hidden | |
| char | c_hidden |
| is the column hidden (set/get) | |
| char | c_numeric |
| is the data numeric (i.e., is getcellvalue implemented) | |
| char | c_draggable |
| can drag the column to rearrange it | |
| char | c_casesensitive |
| use case sensitive sorting (applies only to default text sorting) | |
| void * | c_reference |
| reference for the use of the client | |
| double | c_indentspacing |
| amount of space (in pixels) for one indent level | |
| t_symbol * | c_insertbefore |
| name of column before which this one should have been inserted (used only once) | |
| t_symbol * | c_cellcluemsg |
| message to send requesting clue text for a cell | |
| t_symbol * | c_celltextcolormsg |
| message to get the cell's text color | |
| t_symbol * | c_celltextstylemsg |
| message to get the cell's style and alignment | |
A dataview column.
Columns for a given dataview are stored in a t_hashtab and accessed by name.
Definition at line 117 of file jdataview.h.
